How to Disassemble a Bed Frame Without Wrecking the Fixings

Taking a bed apart is easy. Taking it apart so that it goes back together tight is the part people get wrong, and the damage is almost always done to the same component: the threaded insert in the timber that the bolt screws into. Strip one of those and the frame will never sit square again, no matter how hard you tighten it.

Every Cedora bed frame arrives flat packed with assembly required and two people recommended, so the good news is that they are designed to come apart. The order matters, and so does what you do with the hardware in between.

Key Takeaways

• Photograph every joint before you touch it. Ten photos now saves an hour at the other end.
• Order is fixed: mattress, then base drawers, then slats, then side rails, then headboard and footboard.
• Bag the hardware by joint, label the bags, and tape them to the inside face of the headboard.
• Never take the last bolt out of a joint while the frame is still standing under load.
• On reassembly, snug everything by hand first and only fully tighten once the frame is square.

Before You Start

Photograph it. Every corner joint, both ends of a side rail, the underside of the slat run, and one wide shot of the whole frame. When you rebuild in a new room at nine at night, these are worth more than the instruction sheet you have already lost.

Find the allen key. If it went in the bin three years ago, buy a hex key set before you start rather than halfway through. Using the wrong size key is the fastest way to round out a bolt head.

Clear a staging area. A queen frame breaks into a headboard, a footboard, two side rails and a bundle of slats, and all of it needs somewhere to lean flat while you work.

Measure the exit. A queen headboard is 160cm to 171cm wide and 120cm to 125cm tall, but only 6.8cm to 10.8cm thick. That thinness is what gets it through a standard 820mm doorway on edge. Measure the diagonal of any stair landing before you commit, because that is where a large headboard actually gets stuck.

The Order

1. Strip the bed and remove the mattress. Stand it against a wall on its long edge, not flat on the floor where you will need the space.
2. Pull the base drawers right out if the frame has them. On a London or Manchester drawer base these are separate units and they come out before anything else, not after.
3. Lift out the slats. Most simply sit in a rail or clip in. If they are not identical, number them along one edge in pencil as you go.
4. Support the frame, then release the side rails. This is the step that hurts things. Loosen the bolts at both ends of one rail before removing any of them, keep a hand or a knee under the rail, and only then take the bolts out. A rail dropping under its own weight is what tears the insert out of the timber.
5. Separate the headboard and footboard. With both rails off these are free standing. Lay them flat, face up, on the mattress or a blanket.

Two people for steps four and five on anything above a double. A Manchester king with drawers is 99kg assembled, and even split into parts the headboard is awkward rather than heavy.

London Pine Queen Bed Frame with 2 Drawers

Hardware: the Ten Minutes That Saves the Rebuild

Do not put all the bolts in one container. Bed frames use several lengths that look alike, and a bolt that is 5mm too long will bottom out in the insert and either stop the joint pulling tight or split the timber when you force it.

Use a separate zip bag per joint, write the location on the bag with a marker, and tape all the bags to the inside face of the headboard where they cannot be separated from the frame. Include the allen key in one of them.

Two fittings worth recognising while you are in there:

• Bolts into threaded inserts. A metal sleeve is set into the timber and the bolt screws into it. Strong, reusable many times, and ruined instantly by cross threading.
• Cam locks. A round disc that turns roughly a half turn anticlockwise to release a pin. Never force a cam past its stop, and never lever a joint apart while the cam is still engaged.

Reassembly, Where Frames Get Ruined

The single rule: start every bolt by hand, and start every bolt before you tighten any of them.

A bolt started with a driver at a slight angle will cut a new thread in the insert and strip it. A joint fully tightened before the rest are started will pull the frame out of square, so every later bolt goes in under tension and the whole thing ends up stressed. Get all four corners hand tight, check the frame is square by eye and by feel, then work around tightening in stages.

Do not over torque. These are bolts into timber, not engine bolts. Firm is correct. Another quarter turn past firm is how the insert gets pulled loose, and a loose insert is the most common cause of a bed that squeaks and rocks within a month. If you are already dealing with that, we went through the fixes in how to fix a wobbly bed frame.

Put the slats back in the same order and the same way up. Solid slats have a face and a back, and turning one over changes how it sits in the rail.

Newcastle Acacia Queen Bed Frame

Moving House With It

Wrap the headboard face. It is the piece that gets leaned against a wall, walked past and scraped, and on an upholstered headboard a scuff is not something you can sand out. A moving blanket and two straps is enough.

Keep the slats bundled and tied. Loose slats in the back of a van are the thing that scratches everything else, and a missing slat is far more annoying to replace than it sounds.

Stand rails on end rather than laying them across other furniture. They are long and relatively slender and they take a set if something heavy rests across the middle.

If the frame is going into storage rather than straight into a new room, keep it off a concrete floor and out of a garage that swings between hot and damp. Timber that has spent a summer in a shed does not go back together as squarely as it came apart.

When Not to Take It Apart

If you are moving a bed within the same floor of the same house, and the doorways are 820mm or wider, it is often easier to walk the assembled frame through on its side with two people. Every disassembly and reassembly cycle is another chance to strip a thread, and the fixings are the one part of a timber bed that genuinely wears out.

The exception is a frame with base drawers. Those are heavy, they slide out under their own weight the moment the frame tilts, and they need to come out regardless.

Liverpool Pine Double Bed Frame - Black

Frequently Asked Questions

What order do you take a bed frame apart in?

Mattress first, then any base drawers, then the slats, then the side rails, then separate the headboard and footboard. Loosen the bolts at both ends of a side rail before removing any of them, and support the rail so it cannot drop.

How do you stop stripping the bolts on a bed frame?

Start every bolt by hand rather than with a driver, and start all of them before tightening any. Tighten to firm and stop there. Over torquing pulls the threaded insert out of the timber, which is the most common cause of a frame that never sits tight again.

Will a bed headboard fit through a standard doorway?

Usually yes. A queen headboard is 160cm to 171cm wide and 120cm to 125cm tall but only 6.8cm to 10.8cm thick, so it passes through an 820mm doorway on edge. The place it gets stuck is a stair landing, so measure the diagonal there first.

Do you need two people to take a bed apart?

For anything above a double, yes. Cedora bed frames run from 40kg to 99kg assembled and every one is supplied with two people recommended. The risk is not the weight so much as a side rail dropping while the last bolt comes out.

Should I keep the original bed frame hardware?

Yes, and bag it by joint rather than all together. Bed frames use several bolt lengths that look almost identical, and a bolt that is too long will bottom out in the insert instead of pulling the joint tight.
